Product Overview
The KYD-FB60-3A represents three years of engineering development focused on the needs of modern long-haul logistics operators. It combines industry-leading payload capacity with superior durability and fuel efficiency.
Key Specifications
| Parameter | Specification |
|---|---|
| Model | KYD-FB60-3A |
| Overall Length | 13,600 mm (44.6 ft) |
| Overall Width | 2,550 mm (100.4 in) |
| Deck Height (unladen) | 1,450 mm (57 in) |
| Tare Weight | 6,200 kg (13,670 lbs) |
| Rated Payload | 60,000 kg (132,280 lbs) |
| Axle Configuration | 3-axle, air suspension |
| Axle Brand | BPW ECO Plus (Germany) |
| Brake System | WABCO EBS with ABS |
| King Pin | JOST 2" bolt-on |
| Landing Gear | JOST Modul 25T |
Innovative Features
Advanced Lightweight Construction
The main beams use Q690D high-strength steel with optimized web thickness, reducing weight by 800 kg compared to conventional Q345 designs while maintaining identical load ratings. Crossmembers employ cold-formed channels for additional weight savings without compromising lateral rigidity.
Factory-Installed Aerodynamic Package
Unlike aftermarket add-ons, our aero package is integrated into the trailer structure during manufacturing:
- Full-length side skirts with access panels for maintenance
- Rear tail fairing with flexible extension
- Front gap reducer panel
- Underbody airflow management panels
- Combined fuel savings: 8-12% verified in independent testing
Enhanced Durability for Harsh Conditions
- Complete hot-dip galvanizing of chassis structure (not just primer)
- Sealed wiring harness with Deutsch connectors
- IP67-rated LED lighting throughout
- Stainless steel fasteners in corrosion-prone locations
- Reinforced rear impact guard exceeding ECE R58 requirements
Smart Fleet Integration
- Pre-wired for telematics (GPS, temperature, door sensors)
- Tire pressure monitoring system ready
- Load cell integration points for onboard weighing
- CAN bus compatible with major fleet management platforms
Target Applications
- Long-haul general freight and container transport
- Building materials distribution
- Agricultural bulk transport
- Mining supply chain logistics
- Cross-border international transport
Availability and Pricing
The KYD-FB60-3A is available for order now with first deliveries scheduled for Q3 2026. Volume pricing and fleet discount programs are available for orders of 5+ units.
Contact our sales team for detailed specifications, pricing, and delivery timelines tailored to your market.
